L095 Curved Flexible Jaw Coupling Spider Moter Rubber Shaft

L095 jaw insert flexible spider moter jaw rubber shaft coupling

Product Description

Features of L curved jaw coupling:

Product Summary

Use a flex coupling to direct-mount your engine to pump. Oil-resistant synthetic rubber inserts are used between the coupling halves to provide an equalized cushioned drive. When ordering, get one side to fit the motor and the other side to fit the pump shaft dia. Order two halves plus insert for complete coupling. When mounting, do not pound on the end of your pump shaft.

Lovejoy standard L type Jaw spider coupling parameters and data :

Size	Type	Standard bore	Bore metric		Bore inch		Dimensions					Torgue	Rotational speed rpm	Mass kg
Size	Type	Standard bore	Min	Max	Min	Max	A	B	C	D	E	needed Nm	Rotational speed rpm	Mass kg
L035	1	3	3	8	1/8"	3/8"	16	20.2	7.8	6.6	－	0.5	30.000	0.03
L050	1	6	5	15	3/16"	5/8"	28	43	12	15.6	－	3	17.000	0.13
L070	1	9	7	19	3/16"	3/4"	35	50.7	12.7	19	－	5	13.000	0.24
L075	1	9	9	25	3/16"	1"	45	55	12.7	21	－	10	10.000	0.40
L090	1	9	9	28	3/16"	1 1/8"	54	55	12.7	21	－	16	9.000	0.68
L095	1	9	9	28	3/8"	1 1/8"	54	64	12.7	25.5	－	22	9.000	0.71
L099	1	12	12	35	7/16"	1 3/8"	65	72.5	19	27	－	45	7.000	1.22
L100	1	12	12	35	7/16"	1 3/8"	65	88.5	19	35	－	50	7.000	1.40
L110	1	15	15	48	1/2"	1 7/8"	84	108	22	43	－	90	5.000	3.00
L150	1	15	15	48	5/8"	1 7/8"	96	115.4	25.4	45	－	150	5.000	5.00
L190	2	19	19	55	5/8"	2 1/4"	115	133.4	25.4	54	102	200	4.200	7.60
L225	2	19	19	65	3/4"	2 5/8"	127	153.4	26.4	64	108	300	4.200	9.00
